K-Type Thermocouple Extension Cable Wire with Fiberglass Insulation Mini Connectors 6 ft

K-Type Thermocouple Extension Cable with Fiberglass Insulation and Nylon Miniature Thermocouple Connectors

6 ft length

This listing is for 1 K-Type Thermocouple extension cable with yellow braided fiberglass insulation, with a miniature male and a miniature female K type thermocouple connector. They conform to the miniature connector dimensions with flat blades and the K-Type Thermocouple Extension Wire specification. This means the metal prongs and the wire are made from compensating metal, the same material as the K-type thermocouple wire, which is chromel / alumel. This impact of the extension wire on the temperature reading is minimized.

This K-type extension cables with fiberglass insulation are stable to about 750 F (400 C).  The K-type thermocouple plugs are made from glass filled Nylon and are stable to about 400 F (190 C). The thermocouple plugs have a white label field for easy marking.

These K-type extension cables are frequently used in battery labs for lithium ion and other advanced batteries that are used in handheld devices and electric cars.

This Type K extension wire is available in 3 ft, 6 ft, 9 ft, 12 ft or 15 ft. These K-type extension wires are made to order in St Paul, MN, USA.  Please request a quote if you need a different or custom length.

Specification:
K-Type Thermocouple Wire: chromel / alumel, AWG 24, flexible

Color Code: ANSI K-type yellow

Cable Insulation: Braided fiberglass, stable up to 750 degree Fahrenheit F or 400 degree Celsius C

Connectors: High quality  glass filled nylon housing, stable to 400 degree Fahrenheit or 200 degree Celsius
